  • Cable Connector, plug/male, Angled/90°, DIN1.0/2.3, Crimp Type;
  • Compact design is ideal for limit space application and save space in delivery;
  • Push/pull mating is excellent for quick installation without vibrate loose;
  • Great performance with frequency up to 10GHz support high data rates.
  • High Quality with 30 days 100% Money back;
  • From the OEM Original Factory, same quality with much better price.

Main Application of DIN1.0/2.3 Connectors:

Aerospace and Defense: Communication systems
Telecommunications: CATV, Central office, High-density Radios, Base station, Switching equipment
Networking: Video Equipment, Radio boards

from
$93.60
Ex Tax: $93.60
  • Stock: In Stock
  • Model: JE00002745
  • Weight: 10.00g
  • SKU: JE00002745
Products Sold: 0
Product Views: 3
  • Specifications
attribute-list
Body Material Cooper
Terminal type Solder Type
Installation characteristics None
Gender Male
Function Dustproof
Direction Right Angle
Polarity Standard
Coating Nickel Plating
Impedance 75 Ω
Installation method Cable
Outer conductor connection Crimp
  • Description

Electrical Characteristics

  • Impedance:50 ohm or 75 ohm
  • Frequency Range: 0~4 GHz for 50 ohm, 0~2 GHz for 75 ohm
  • VSWR: Straight type ≦ 1.3max / R/A type ≦ 1.5max
  • Dielectric Withstanding Voltage: 750 V rms
  • Working Voltage: 250 V rms
  • Center Contact Resistance ≦ 6.0 mΩ  (Milliohms max.)
  • Outer Contact Resistance  3.0 mΩ  (Milliohms max.)
  • Insultation Resistance ≧ 10

Mechanical Characteristics

  • Coupling: Push-pull
  • Contact Retention: 4 lbs min.
  • Mating Durability: ≧500 cycles (For Beryllium Copper Contact)

Environmental Characteristics

  • Environmental Characteristics: -40°C ~ +155°C
