HDMI male connector 19p Straight DIP for PCB 10pcs

Applications:

• * HDMI output device to an amplifier with HDMI input, and to a flat TV or projector
• * used for various brands of LCD, LCD TV connected computer or DVD
• * SONY CX7/ SONY SR7E and LCD TV or projector with HDMI interface
• * support MINI Display Port-HDMI conversion, support HDTV1080p, support audio, video integrated transmission

Electrical Characteristics

• Connector plating:Gold-plated ,Nickel-plated
• Wire core: pure copper
• Conductor : Bare copper ,Tinned copper or optional
• Over mold:PVC 80Pa ,UL94V-0 Black
• Pre mold: PE Low Density
• Jacket Color: BLUE,BLACK,WHITE or optional

Mechanical Characteristics

• Withdraw Force：10N Min
• Insertion Force： 35N Max
• Contact Resistance：0.01 OHM Max
• Insulation Resistance： 10M OHM /300V Min
• Hi-Pot : DC 300V 10ms
• Compatibility: HDMI1.1/1.2/1.3

Environmental Characteristics

• Temperature Range：-25°C~ +85°C
